DJJ150 Industrial Horizontal Powered Double Shaft Mixer

I'm Online Chat Now

DJJ150 Industrial Horizontal Powered Double Shaft Mixer

DJJ150 Industrial Horizontal Powered Double Shaft Mixer
DJJ150 Industrial Horizontal Powered Double Shaft Mixer DJJ150 Industrial Horizontal Powered Double Shaft Mixer

Large Image :  DJJ150 Industrial Horizontal Powered Double Shaft Mixer

Product Details:
Place of Origin: CHINA
Brand Name: BOHAI
Certification: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: USD
Packaging Details: CONTAINER
Delivery Time: 620DAYS
Payment Terms: T/T
Supply Ability: 50SETS
Detailed Product Description
Model: DJJ150 Production Capacity: 50-80 (m3/h)
Overall Dimension: 7500×1500×1000 (mm) Agitator Shaft Speed: 40r/min
Mixing Diameter: 680(mm) Machine Type: Automatic
Warranty: 1 Year Raw Material: Clay , Coal Gangue, Shale And Fly Ash
High Light:

DJJ150 Double Shaft Mixer

,

40r/min Double Shaft Mixer

,

80m³/h Double Shaft Mixer

CB- Dual-Axle Strong Clay Stirring Machine



1, Product features:


It applies to raw material like clay, coal gangue, shale and fly ash, fully stirring and mixing the material with water to increase its plasticity.

2, Technical parameters:



Date Units of meas DJJ90
Production capacity M3/h 40-60
Agitator shaft speed r/min 36
Power kw 110
Overall dimension mm 7600×2100×1700



Date Units of meas DJJ120
Production capacity M3/h 50-80
Agitator shaft speed r/min 32
Power kw 132
Overall dimension mm 7900×2300×1750



Date Units of meas DJJ150
Production capacity M3/h 60-100
Agitator shaft speed r/min 32
Power kw 160
Overall dimension mm 8500×2500×1850





Advantages



Double Shaft Mixer in Brick Making Machinery
1) Good mixing effect
2) Large output
3) Flexible install, steady running
4) 48-year credit



Feature


1. Large output and stable machine performance.
2. High efficiency and work continuously.
3. Special blade arrangement ensure the raw material stir uniformity.
4. Service a long span time and easy to operate.



Specifications


1. Add water into raw material to mix fully, enhance raw material comprehensive performance , improve the quality , appearance and output.
2. Good mixing effect and easy maintenance .
3. Simple operation , high capacity , uniform mixing .
4. It is an essential raw material dealing equipment for making brick .
